LYNRED Linear PEGA new

Specially designed for earth observation space imaging applications
Download datasheet

Versatile architecture

100% operability

Space proven architecture

On board Trishna mission

LYNRED Linear PEGA is a large linear detector specially tailored for earth observation applications from MWIR up to VLWIR spectral range. Based on LYNRED space proven MCT technology, LYNRED Linear PEGA detector, developped in the frame of TRISHNA mission offers the highest level in terms of performance (100% operability, high frame rate, large dynamic range...) and versatility (compatible design with staggered/butted configuration, external TDI, gain selection, integration time adjustment per readout line...).

Features

  • Sensitive Array

    4 channels [8 – 12μm] / 2 arrays (LWIR & VLWIR)

  • Format & Pixel pitch

    9 readout lines of 600 pixels / 30 μm pixel pitch (nominal)

  • Operating temperature

    60K (nominal)

  • ROIC architecture

    Snapshot integration type (IWR & ITR mode) - External TDI (3 readout line per channel)
    1 analog output per readout line (Pseudo-differential mode, 2.6V maximum output voltage swing)

  • Operating characteristics

    Nominal Frame rate: 4.5 kHz @3MHz pixel rate (Available operation up to 8MHz pixel rate)
    Integration time: From 15 μs up to (Frame time – 15μs)
